Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port

Shenzhen Sibo Industrial & Development Co., Ltd.
Contact Now
    Buy cheap Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port from wholesalers

    Buy cheap Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port from wholesalers
    • Buy cheap Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port from wholesalers
    • Buy cheap Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port from wholesalers
    • Buy cheap Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port from wholesalers
    • Buy cheap Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port from wholesalers
    • Buy cheap Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port from wholesalers

    Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port

    Ask Lasest Price
    Brand Name : SIBO
    Model Number : Q896S
    Certification : CE, FCC
    Payment Terms : T/T
    Supply Ability : 2000pcs/month
    Delivery Time : 5-25 working days
    • Product Details
    • Company Profile

    Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port

    Industrial Universal Tablet with RS232 RS285 UART GPIO Interface port


    We have a better solution for:

    • Meeting Room Booking System
    • Access Control System
    • Time & Attendance System
    • Smart House Control Center
    • Inventory Tracking & managing System
    • Library Guiding System
    • Hospital Room Access & Information System
    • Asset and Document management System
    • Laundry management system

    All you need in one box

    We have:

    • Glass surface, Button free design
    • Top fading LED
    • HDMI
    • Power over Ethernet
    • Build-in NFC / RFID card reader
    • Multiple network support

    We could:

    • One year warranty
    • Hardware modifying
    • Software customizing
    • Full technical support

    Products Pictrues

    POE Supported:

    POE(Power Over Ethernet) is a technology that lets network cables carry electrical power.RJ45 POE


    Build-in NFC / RFID reader:

    Demo apk for NFC


    Build-in Arduino Board:

    896+arduino-back2


    Unique Arduino Module:

    We have a built in Arduino I/O board in our tablet. That gives our tablet a unique ability that it could work with most of sensors or other components. Also, it is very easy to make a change on our system. If you want to use another sensor or add more sensors, just simply plugin then update the control program.

    Android-to-Arduino Uploader:

    Writing a new program into the Arduino board isn’t an easy job normally. You need a program writer to do so. However, our tablet has a unique design that you can actually upload your program from the tablet directly. After purchase our product, the product will come with a using guide and an Android APP which you can use it to upload.


    Temperature and Humidity Sensor

    TH sensor.jpg


    RS485 / RS232:

    Q896 rs485


    Unique On Glass Mount Bracket:

    Easy to mount on glass. Sample and clean


    HTB1Ch0xIVXXXXXGaXXXq6xXFXXXM

    On wall with L shape bracket

    onwall mount.jpg


    Wall mount with metal box

    7 (2).jpg8 (2).jpg9 (2).jpg


    In wall mount method:

    518a80dd0a20c9b3a11b46d0b19c


    Table Mount

    desk mount.jpg


    Technical Details
    Model NumberQ896S
    Hardware SpecsProcessorAllwinner A83T processor
    CPU8-Core ARM Cortex A7 CPU, 1.2Ghz
    Display7 Inch IPS Display, Resolution:1024 x 600, Brightness: 350 cd/m2
    RAM2GB
    Nand Flash8GB
    Software FeatureSystemGoogle Android 4.4.4
    VideoH.264 2160p video decoding,
    Multi-format FHD video decoding, including Mpeg1/2, Mpeg4 SP/ASP GMC, H.263, H.264, VP6/8, AVS jizun, Jpeg/Mjpeg,etc.
    H.264 High Profile 1080p@30fps or 720@60fps encoding
    3840 x 1080@30fps 3D decoding, BD/SBS/TAB/FP supported
    Complies with RTSP, HTTP, HLS, RTMP, MMS streaming media protocols
    AudioTwo Speakers 2 X 1 Watt (Integrated 3W Amplifier For External Speakers)
    LanguageSupport multi-languages
    InterfacesBackHDMI Out
    DC IN Power Terminal (9V-36V)
    Ethernet Interface(RJ45)
    USB Socket HOST Mode By Default, Optional: Jumper Cap For Device Mode
    Optional:RS232,RS485
    NetworkWIFI+BLUETOOTHWIFI (802.11b/g/n), Bluetooth V2.1+EDR/BT v3.0/BT v3.0+HS/BT v4.0
    LAN PortEthernet RJ45
    Power SupplyDC INDC 9V - 36V
    Boot UpAuto BootAuto Boot Up When Power Supplies
